Table 3.5.1 · MODBUS register map - conguraon registers (connued)
REGISTER
NUMBER
NAME DESCRIPTION
OPTIONS and
REGISTER VALUE
DEFAULT
DATA
TYPE
READ
or
WRITE
126
MODBUS
BAUDRATE
Baud rate of the ARControl
Modbus communicaons through
the Modbus RS-485 port
Baud Rate:
bits/second
Value
100 UINT16 R/W
2400 0
4800 1
9600 2
19200 3
38400 4
57600 5
115200 6
230400 7
127
MODBUS
WORD ORDER
Word order of the ARControl
Modbus communicaons through
the Modbus RS-485 port
Word Order Value
0 UINT16 R/W
Most
signicant
word rst
1
Least
signicant
word rst
0
128 - 129 UNUSED Unused N/A R
130
DATA LOG
CONTRACT
HOUR
Contract hour
Range Value
0 UINT16 R/WMin 0
Max 23
131
DATA LOG
DOWNLOAD
MODE
Whether all data logs in memory
are downloaded or all new data
logs since the last retrieval are
downloaded
Range Value
0 UINT16 R/WLAST 0
ALL 1
132
DATA
LOG LOG
FREQUENCY
The frequency, in minutes, at
which data logs are created.
Range Value
60 UINT16 R/WMin 5
Max 60
133 - 134 UNUSED Unused N/A R
135 TRANSDUCER
The span to be applied to the
transducer measurement as
calibraon. See secon 4.6
Transducer Calibraon
Range Value
800 INT16 R/WMin -32768
Max 32767
136
TRANSDUCER
ZERO
The amount of oset to be
applied to the transducer
measurement as calibraon to
“zero out” the measurement
Range Value
0 INT16 R/WMin -32768
Max 32767
