Page #220 background image
204
Enter Setup
1564 Barcode Scanner
User Guide
79 (y) Chinese 25
5A (Z) N/A 7A (z) Aztec
5B ( [ ) GS1 DataBar (RSS) 7B ({) Micro QR
7C (|) USPS 4CB / One Code /
Intelligent Mail
7D (}) UPU FICS Postal
7E (~) UCC Coupon Extended Code
3) Barcode Length setting – read the “Decimal Value” barcode on page 263 for the
4-digit length of the (first) barcode. For example, read “0065” for barcode length of
65 characters or read “0000” for any length.
Note: If not reading 0000 for any length, the 4-digit length must exclude prefix, suffix
(0x0d by default), length code, etc.
4) Matching Character setting – read the “Hexadecimal Value” barcode on page 264 for
the 1
st
character that must be found matching in the (first) barcode. For example,
read “4” and “1” for matching character “A” as the first character in the barcode or
read “00” for any character.
5) Read twice the “F” barcode on page
264 (“FF”) to complete the setting of each
barcode.
6) Read the “Validate” barcode to end the editing of the barcode set.
5.6.2 ACTIVATE THE CONCATENATION OF BARCODES
By default, the output sequence editing of the concatenation of barcodes is not applied.
When “Enforce Output Sequence” is enabled, all barcodes read by the scanner must meet
with the criteria for the concatenation. If data is found excluded from all output sequence
sets (= not meeting with the criteria), the scanner will not accept the reading, and
therefore, data will not be transmitted.
When “Apply Output Sequence” is enabled, only barcodes found meeting with the criteria
are counted for the concatenation. Those found not meeting with the criteria are
processed normally and individually.
Note: When it requires reading more barcodes to complete the “output sequence”
requirements, the scanner will respond with one short beep (low tone). After
reading an acceptable barcode, its LED indicator will become solid green and go off
quickly (= Good Read).
Upon completion of reading acceptable barcodes, the scanner will respond with
one short beep (high tone) and its LED indicator will become solid green and go off
quickly (= Good Read).

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the CipherLab 1564 and is the answer not in the manual?

CipherLab 1564 Specifications

General IconGeneral
TypeHandheld bar code reader
Wavelength625 nm
Sensor typeCCD
Read rate (max)60 reads/s
Tilt reading angle-60 - 60 °
Optical sensor resolution752 pixels
Linear (1D) barcodes supportedCodabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), MSI, U.P.C.
2D (matrix & stacked) barcodes supportedAztec Code, Composite Codes, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Wireless range90 m
Bluetooth version2.0+EDR
Operating frequency2400 MHz
Standard interfacesBluetooth
Connectivity technologyWired & Wireless
CertificationBSMI, CE, C-tick, FCC, IC, NCC, KC, SRMC, TEL
Product colorBlack
Housing materialThermoplastic urethane (TPU)
Protection featuresShock resistant
International Protection (IP) codeIP30
Battery life16 h
Input voltage5 V
Battery voltage3.7 V
Battery capacity800 mAh
Power consumption230 mA
Power source typeBattery, DC
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth153 mm
Width61 mm
Height93 mm
Weight185 g
