CipherLab 1564 User Manual

23
Update
This chapter explains the features and usage of the barcode scanner.
IN THIS CHAPTER
1.1 Battery..................................................................... 23
1.2 Memory.................................................................... 28
1.3 LED Indicator ............................................................ 31
1.4 Beeper..................................................................... 33
1.5 Send “NR” to Host ..................................................... 37
1.6 Scan Modes .............................................................. 38
1.7 Scanning Timeout...................................................... 42
1.8 Delay between Re-read............................................... 43
1.9 Read Redundancy (1D)............................................... 44
1.10 Addon Security for UPC/EAN Barcodes ........................ 45
1.11 Auto-Sense Mode..................................................... 46
1.12 Negative Barcodes ................................................... 47
1.13 Picklist Mode ........................................................... 48
1.14 Mobile Phone/Display Mode ....................................... 49
1.15 Illumination Brightness............................................. 49
1.16 Serial Number Stamp ............................................... 50
1.1 BATTERY
The scanner is powered by a rechargeable 3.7 V/800 mAh Li-ion battery, and it takes
approximately 5 hours to charge the battery to full (from the power adaptor). However,
the charging time may vary by working condition. For intensive data collection, you may
need a spare battery for uninterrupted operation.
Note: The scanner supports power economy. Refer to settings of “
Power Economy”,
“Sniff Mode”, as well as “Low Battery Alarm”.
1.1.1 TURN ON/OFF THE SCANNER
Turn on the scanner…
After installing the battery, pull down the trigger for about 2 seconds. The scanner will respond
with a long beep (high tone), then the LED will become solid red and go off quickly.
Turn off the scanner…
Remove the battery directly or let it turn off automatically in specific circumstances.
Chapter 1
UNDERSTANDING THE BARCODE SCANNER

CipherLab 1564 Specifications

General

Type	Handheld bar code reader
Wavelength	625 nm
Sensor type	CCD
Read rate (max)	60 reads/s
Tilt reading angle	-60 - 60 °
Optical sensor resolution	752 pixels
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), MSI, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Wireless range	90 m
Bluetooth version	2.0+EDR
Operating frequency	2400 MHz
Standard interfaces	Bluetooth
Connectivity technology	Wired & Wireless
Certification	BSMI, CE, C-tick, FCC, IC, NCC, KC, SRMC, TEL
Product color	Black
Housing material	Thermoplastic urethane (TPU)
Protection features	Shock resistant
International Protection (IP) code	IP30
Battery life	16 h
Input voltage	5 V
Battery voltage	3.7 V
Battery capacity	800 mAh
Power consumption	230 mA
Power source type	Battery, DC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	153 mm
Width	61 mm
Height	93 mm
Weight	185 g
