Appendix II

Host Serial Commands

For example, ‘#@GLED,09’ is to have the scanner blink for 9 times.

“0x23” + “0x40” + “0x47” + “0x4c” + “0x45” + “0x44” + “0x2c” + “0x30”

+ “0x39” + “0x0d”

EXAMPLE

You may run HyperTerminal.exe on the host computer to send serial commands to the

1564 scanner via RS-232, USB Virtual COM or BT SPP.

 For the scanner to stop immediately –

 For the scanner to resume working –

 For the scanner to change the beeper to medium volume and beep –

#@101011<CR>

#@////<CR>

 For the scanner to change the beeper to minimal volume and beep –

#@101010<CR>

#@////<CR>

 For the scanner to change the beeper frequency to 8 kHz (for Good Read Beep only)

and beep –

#@101001<CR>

#@////<CR>

 For the scanner to change the beeper length to longest (for Good Read Beep only)

and beep –

#@101008<CR>

#@////<CR>

 For the scanner to save the settings, send the serial command “#@109999” –

#@101011<CR>

#@109999<CR>

 For the scanner to read the serial number and beep –

#@RDSN<CR>

#@////<CR>

 For the scanner to beep for nine times –

#@BEEP,09<CR>

 For the scanner’s LED indicator to blink in red for nine times –

#@RLED,09<CR>

 For the scanner’s LED indicator to blink in green for nine times –

#@GLED,09<CR>
