----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 33
b.- ALARM conditions (1 condition for each relay): If any other parameter (1 to 30)
is selected in (1), two outputs can be configured as alarms. For each output it is
possible to program:
c Any of the parameters measured by the CVMk
d MAXIMUM value
e MINIMUM value
f Delay for the conditions
These screens are successively displayed by the CVMk once the parameter has
been selected ( for the setup of each option proceed as in the Section a.-):
b.1.- Programming the maximum value to be controlled:
OUT 1 RELAY 1
AL hI
0.000
( Maximum value
b.2.- Programming the minimum value to be controlled:
OUT 1 RELAY 1
AL LO
0.000
( Minimum value
b.3.- Programming the delay:
OUT 1 RELAY 1
SEC Delay in seconds
0.000
( maximum 9999 sec.
- Press "display" to pass to the next option: the setup for the second relay
appears (only with modules type CVM-ERC-2 or CVM-RED-C2).
