4�- OPERATION
4.1.- DISPLAY
The device features a 5-digit LED display, which is used to display the measured parameters
and to congure these parameters
Display
Keyboard
00000
Figure 5: Display DHC-96�
4.2.- KEYBOARD FUNCTIONS
The DHC-96 Aac features 4 keys to display and congure the device, Figure 5.
Table 5: Keyboard functions�
Key Keystroke
Previous screen
In the conguration menu:
Scroll through the digits
Next screen
In the conguration menu:
Increase the value of the digit
Long keystroke (> 3s):
Enter in conguration menu
In the conguration menu:
Jump to the next level / Conrm an operation
