7�- TECHNICAL FEATURES
AC Power supply
(2)
Rated voltage 80 ... 270 V ~
Frequency 50 / 60 Hz
Consumption 2.6 ... 4.9 VA
Installation category CAT III 300 V
DC Power supply
(2)
Rated voltage 80 ... 270 V 18 ... 36 V
Consumption 1.5 ... 1.6 W 1.2 W
Installation category CAT III 300 V
(2)
Depending on model :
Model
Power supply
80 ��� 270 V ~ 80 ��� 270 V 18 ��� 36 V
M22358
 
-
M223580030000
- -

Current measurement circuit
Nominal current (In) 1 A ~ / 5 A ~
Frequency measurement margin 45 ... 65 Hz
Overload 1.2 In continuous, 10 In Instantaneous (5s)
Consumption < 0.2 VA
Impedance < 20 mΩ
Installation category CAT III 300V
Measurement accuracy
Current measurement 0.5%
Relays outputs
Quantity 2
Contact capacity (resistive) CA: 5A / 250 V~ , CC: 5A / 30 V
Max� voltage open contacts 277 V~
Maximum current 5 A ~
Maximum switching power 1385 VA
Electrical life (250 V~ / 5A) 1x10
5
Mechanical life 5x10
6
Digital inputs
Quantity 2
Type Potential free contact
Insulation 2000 V~
Maximum short-circuit current 3.3 mA
Maximum voltage in open circuit 17 V
Analog output
Quantity 1
Maximum internal voltage 17 V
Linearity 0.5 %
Nominal output range 0-20 mA, 4-20 mA, 4-12-20 mA (Programmable)
Maximum load resistor 350 Ω
