Response:
Address Function
Initial
Register
Relay action CRC
01 05 0000 FF00 8C3A
6.3.- MODBUS COMMANDS
6�3�1�- MEASUREMENT VARIABLES AND DEVICE STATUS
All the addresses of Modbus memory are in Hexadecimal.
For these variables is implemented the Function 0x03 and 0x04.
Table 7: Modbus memory map (Table 1)
Parameter Format Address Units
Current oat 12 A
Current int 10C 0.001 A
Frequency oat 2C Hz
Frequency int 120 0.01 Hz
Table 8: Modbus memory map (Table 2)
Parameter Format Address Value
Status of output relays bit [0] - bit [2] bit [32] 100 - 101
0: open
1: closed
Status of digital inputs bit [0] - bit [2] bit [32] 102 - 103
0: open
1: closed
Communications ID int 104 504
6�3�2�- OUTPUT RELAYS
All the addresses of Modbus memory are in Hexadecimal.
For these variables is implemented the Function 0x01, 0x05 and 0x0F�
Table 9: Modbus memory map (Table 3)
Parameter Format Address Value
Output relay 1 bit 0000 0: open, 1: closed
Output relay 2 bit 0000 0: open, 1: closed
6�3�3�- DIGITAL INPUTS
All the addresses of Modbus memory are in Hexadecimal.
For these variables is implemented the Function 0x02�
Table 10: Modbus memory map (Table 4)
Parameter Format Address Value
Digital input 1 bit 0000 0: open, 1: closed
Digital input 2 bit 0000 0: open, 1: closed
