Cisco 11503 - CSS Content Services Switch - Page 363

B-13
Cisco Content Services Switch Administration Guide
OL-5647-02
Appendix B Using the Offline Diagnostic Monitor Menu
• Make sure you properly connect the Ethernet management port on the CSS to
the network:
– CSS 11503 or CSS 11506 - SCM 10 Mbps-Ethernet management port
– CSS 11501 - Front panel 10 Mbps-Ethernet management port
• Be aware of the following network boot restrictions:
– A network boot is not supported on UNIX workstations.
– The War-FTP daemon is not supported for network-booting the system
software.
When you select Network, the CSS prompts you for the FTP kernel information.
1. Enter the FTP kernel path information. This path is the FTP daemon
addressable location where the boot image has been unpacked. You must also
include the FTP server IP address and the username and password to access
the boot image. For example:
Enter the FTP Kernel path:[] k:/sg0720104/hdd
Enter FTP Server IP address:[] 10.3.6.58
Enter FTP Server authentication username:[] mandy
Enter FTP Server authentication password:[] fred
2. Enter an alternate path to the configuration files, including the startup-config
and script files, if the configuration information is not in the same directory
as the boot image.
Note The CSS must be able to access the configuration path through the
previously configured FTP server IP address, login username, and
password.
For example:
Enter the FTP Config Path? [] k:/atlanta-config/
Press <Enter> to continue...
3. Press Enter to display the Boot Configuration menu.
4. Enter r to display the Offline DM Main menu.
5. Select option 4 to reboot the CSS.
