8-35
Cisco Wireless LAN Controller Configuration Guide
OL-17037-01
Chapter 8 Controlling Mesh Access Points
Configuring Advanced Features
• To view the total number of voice calls and the bandwidth used for voice calls on each root access
point, enter this command:
show mesh cac summary
Information similar to the following appears:
AP Name Slot# Radio BW Used/Max Calls
------------ ------- ----- ----------- -----
SB_RAP1 0 11b/g 0/23437 0
1 11a 0/23437 2
SB_MAP1 0 11b/g 0/23437 0
1 11a 0/23437 0
SB_MAP2 0 11b/g 0/23437 0
1 11a 0/23437 0
SB_MAP3 0 11b/g 0/23437 0
1 11a 0/23437 0
• To view the mesh tree topology for the network and the bandwidth utilization (used/maximum
available) of voice calls and video links for each access point and radio, enter this command:
show mesh cac bwused {voice | video} Cisco_AP
Information similar to the following appears:
AP Name Slot# Radio BW Used/Max
------------- ------- ----- -----------
SB_RAP1 0 11b/g 1016/23437
1 11a 3048/23437
|SB_MAP1 0 11b/g 0/23437
1 11a 3048/23437
|| SB_MAP2 0 11b/g 2032/23437
1 11a 3048/23437
||| SB_MAP3 0 11b/g 0/23437
1 11a 0/23437
Note The bars (|) to the left of the AP Name field indicate the number of hops that the mesh access
point is away from its root access point (RAP).
Note When the radio type is the same, the backhaul bandwidth used (bw used/max) at each hop
is identical. For example, mesh access points map1, map2, map3, and rap1 are all on the
same radio backhaul (802.11a) and are using the same bandwidth (3048). All of the calls are
in the same interference domain. A call placed anywhere in that domain affects the others.
• To view the mesh tree topology for the network and display the number of voice calls that are in
progress by access point radio, enter this command:
show mesh cac access Cisco_AP
