Chapter 2 Getting Started with Your Cisco SIP IP Phone
Installing the Cisco SIP IP Phone
2-12
Cisco SIP IP Phone 7960 Administrator Guide
78-10497-02
Step 5
Highlight and press the Select soft key to configure the following parameters:
•
Name—(Required) Number or e-mail address used when registering. When
entering a number, enter the number without any dashes. For example, enter
555-1212 as 5551212. When entering an e-mail address, enter the e-mail ID
without the host name.
•
Authentication Name—(Required when registration is enabled) Name used
by the phone for authentication if a registration is challenged by the proxy
server during initialization. If a value is not configured for the Authentication
Name parameter when registration is enabled, the default name is used. The
default name is SIPmacaddress where macaddress is the MAC address of the
phone.
•
Authentication Password—(Required when registration is enabled) Password
used by the phone for authentication if a registration is challenged by the
proxy server during initialization. If a value is not configured for the
Authentication Password parameter when registration is enabled, the default
logical password is used. The default logical password is SIPmacaddress
where macaddress is the MAC address of the phone.
•
Proxy Address—(Required for the first line configured on the phone) IP
address of the primary SIP proxy server that will be used by the phone. Enter
this address in IP dotted-decimal notation.
Step 6
Press the Back soft key to exit the Line 1 Configuration menu.
Step 7
To configure additional lines on the phone, highlight the next Line x Settings,
press the Select soft key and repeat Step 5 and Step 6.
Step 8
When done, press the Save soft key to save your changes and exit the
SIP Configuration menu.
Caution
When you have completed your changes, ensure that you lock the
phone as described in the “Locking Configuration Mode” section on
page 3-2.
