Cisco 7961G Administration Guide

C-3
Cisco IP Phone Administration Guide for Cisco CallManager, Cisco IP Phone 7961G/7961G-GE and 7941G/7941G-GE
OL-6966-01
Appendix C Technical Specifications
Network and Access Port Pinouts
Network Port Connector
Table C-2 describes the network port connector pinouts.
Access Port Connector
Table C-3 describes the access port connector pinouts.
Table C-2 Network Port Connector Pinouts
Pin Number Function
1TD+
2TD–
3RD+
4Not used
5Not used
6RD–
7Not used
8Not used
Table C-3 Access Port Connector Pinouts
Pin Number Function
1RD+
2RD–
3TD+
4Not Used
5Not Used
6TD–
7Not Used
8Not Used
