The following table lists the supported CPAK transceivers that can be used in the EPA-1x100GE Ethernet

port adapter.

Table 5: Supported CPAK Interface

DescriptionPID

CPAK 100GBASE-SR10

Delivers 100-Gbps links over 24-fiber ribbon cables terminated with

MPO/MTP connectors. It supports link lengths of 100m and 150m on

laser-optimized OM3 and OM4 multifiber cables. OTN rates are also

supported.

CPAK-100G-SR10

CPAK 100GBASE-LR4

Supports 100-Gbps optical links over standard single-mode fiber (SMF,

G.652) terminated with SC connectors. Nominal power consumption

is less than 5.5W.

The LR4 module is IEEE 802.3ba-compliant and supports link lengths

of up to 10 km over standard SMF, G.652. It delivers an aggregate data

signal of 100-Gbps, carried over four wavelength-division multiplexing

(WDM) wavelengths operating at a nominal 25 Gbps per lane in LAN

mode. OTU4 rate is also supported. Optical multiplexing and

demultiplexing of the four wavelengths are managed within the module.

CPAK-100G-LR4

Supported Crypto Module

The Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router support the following crypto module:

DescriptionPID

Cisco ASR1001-HX crypto module with no default crypto throughput.

You can upgrade the throughput (8 Gbps or 16 Gbps) by applying a

software-activated performance upgrade license.

ASR1001HX-IPSECHW

Cisco ASR1002-HX crypto module with no default crypto throughput.

You can upgrade the throughput (8 Gbps, 16 Gbps, or 25 Gbps) by

applying a software-activated performance upgrade license.

ASR1002HX-IPSECHW
