Chassis height meets EIA-310 rack spacing, universal rack mount
◦ Cisco ASR 1001-HX Router—1RU (1.75 in. or 44.45 mm)
◦ Cisco ASR 1002-HX Router—2RU (3.5 in. or 88.9 mm)
•
Chassis width meets EIA-310 19 in. (17.3 in. or 439.42 mm) wide with rack brackets
•
Cable-management brackets allow a bend radius of 1.5 in. (38.1 mm) for cables
•
Ships with forward rack-mount brackets installed and an extra set included in the accessory kit
Site Power Guidelines
The Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router has specific power and electrical wiring
requirements. Adhering to these requirements ensures reliable operation of the system. Follow these precautions
and recommendations when planning your site for the Cisco ASR 1001-HX Router and Cisco ASR 1002-HX
Router:
•
The redundant power option provides a second, identical power supply to ensure that power to the chassis
continues uninterrupted if one power supply fails or input power on one line fails.
•
In systems configured with the redundant power option, connect each of the two power supplies to a
separate input power source. If you fail to do this, your system might be susceptible to total power failure
due to a fault in the external wiring or a tripped circuit breaker.
•
To prevent a loss of input power, be sure the total maximum load on each circuit supplying the power
supplies is within the current ratings of the wiring and breakers.
•
Check the power at your site before installation, and periodically after installation, to ensure that you
are receiving clean power. Install a power conditioner if necessary.
•
Provide proper grounding to avoid personal injury and damage to the equipment due to lightning striking
power lines or due to power surges. The chassis ground must be attached to a central office or other
interior ground system.
This product requires short-circuit (overcurrent) protection to be provided as part of the building installation.
Install only in accordance with national and local wiring regulations.
Caution
The Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router installation must comply with all
applicable codes and is approved for use with copper conductors only. The ground bond fastening hardware
should be of compatible material and preclude loosening, deterioration, and electrochemical corrosion of
hardware and joined material. Attachment of the chassis ground to a central office or other interior ground
system must be made with an AWG #6 gauge wire, copper ground conductor at a minimum.
Note
Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router Hardware Installation Guide
37
Preparing Your Site for Installation
Site Power Guidelines
