Electrical Circuit Requirements
Each Cisco ASR 1001-HX Router or Cisco ASR 1002-HX Router requires a dedicated electrical circuit. If
you equip it with dual-power feeds, you must provide a separate circuit for each power supply to avoid
compromising the power redundancy feature.
The Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router can be powered by a DC or AC source.
Ensure that equipment grounding is present and observe power-strip ratings. Make sure that the total ampere
rating of all the products plugged into the power strip does not exceed 80 percent of the rating.
The Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router can support two AC or two DC power
supplies. Do not install mixed AC and DC power supply units in the same chassis.
Note
The following table contains specifications for DC-powered systems for the Cisco ASR 1001-HX Router and
Cisco ASR 1002-HX Router.
Table 9: Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router DC Power Supply System Input Requirements
AWG # WireCircuit Breaker AmpsSystem Input Rating
(Amps)
MaximumMinimum
10503526
The Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router AC power supply requires a 20 A
circuit breaker.
Note
The following table lists AC and DC power supply system rating requirements for the Cisco ASR 1001-HX
Router and Cisco ASR 1002-HX Router.
Table 10: AC and DC Power Supply System Rating Specifications for the Cisco ASR 1001-HX Router and Cisco ASR 1002-HX
Router
SpecificationDescription
AC = 85–264 VAC
DC = –40–72 VDC
Power supply declared ratings
50/60 Hz for AC power suppliesLine frequency rating
Site Cabling Guidelines
This section contains guidelines for wiring and cabling at your site. When preparing your site for network
connections to the Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router, consider the type of cable
Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router Hardware Installation Guide
38
Preparing Your Site for Installation
Site Cabling Guidelines
