Table 5: Supported Interface Modules and Part Numbers for N560-RSP4 and N560-RSP4-E
SlotPart NumberInterface ModulesRSP Module
Not SupportedA900-IMA8S8-port Gigabit Ethernet SFP Interface
Module (8X1GE)
N560-RSP4
and
N560-RSP4-E
Not SupportedA900-IMA8T8-port Gigabit Ethernet RJ45
(Copper) Interface Module (8X1GE)
Not SupportedA900-IMA1X1-port 10 Gigabit Ethernet XFP
Interface Module (1X10GE)
Not SupportedASR900-IMA8S1ZSFP Combo IM—8-port Gigabit
Ethernet (8X1GE) + 1-port 10 Gigabit
Ethernet (1X10GE)
Not SupportedASR900-IMA8T1ZCopper Combo IM—8-port Gigabit
Ethernet (8X1GE) + 1-port 10 Gigabit
Ethernet Interface Module (1X10GE)
Not SupportedASR900-IMA2Z2-port 10 Gigabit Ethernet Interface
Module (2X10GE)
7,9N560-IMA2C2x100G Interface module
0,1,2,3,4,5,6,7,8,9,10,11,12,13,14
and 15
A900-IMA8CS1Z-M8-port SFP/8-port CSFP Gigabit
Ethernet (8/16X1GE) + 1-port 10
Gigabit Ethernet (1X10GE) Interface
module
4,5,7,9,10 and 11A900-IMA8Z8x10G Interface module
RSP Redundancy
The Cisco ASR 907 Router chassis includes two RSP slots to allow for redundant RSPs. When the router uses
redundant RSPs, one RSP operates in the active mode and the other operates in the hot standby mode. Removal
or failure of the active RSP results in an automatic switchover to the standby RSP.
If you are using redundant RSPs, both the RSPs must be of the same type because a mixed configuration of
two different RSP types is not supported.
Note
Network Timing Interfaces
The RSP supports the following network timing interfaces:
• BITS input/output port—RJ48 jack
• 1 PPS input and output—Mini coax connectors
• 2.048 or 10 MHz input and output—Mini coax connectors
• Time of Day (ToD) or 1 PPS input or output port—Shielded RJ45 jack
Cisco ASR 907 Router Hardware Installation Guide
12
Cisco ASR 907 Router Overview
RSP Redundancy

Cisco ASR 907 Specifications
