Configuring MPLS Layer 2 VPNs
Configuring Gigabit EtherChannel for Virtual Private Wire Service
20
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Changes the privilege level for the corresponding CLI
session.
Step 2
configure terminal
Example:
Router# configure terminal
Enters the global configuration mode.
Step 3
mpls label protocol ldp
Example:
Router# mpls label protocol ldp
Specifies that LDP is the default label distribution
protocol.
Step 4
interface loopback loopback-interface-number
Example:
Router# interface loopback 1
Specifies the loopback interface, and enters the interface
configuration mode.
Step 5
ip address ip-address mask
Example:
Router# ip address 10.10.2.1 255.255.255.0
Sets the IP address and mask for the loopback interface.
Step 6
exit
Exits the interface configuration mode.
Step 7
pseudowire-class pw-class-name
Example:
Router(config)# pseudowire-class gec-bridged
Specifies the name of a Layer 2 pseudowire class and
enters the pseudowire class configuration mode.
Step 8
encapsulation mpls
Example:
Router(config-pw)# encapsulation mpls
Uses MPLS as the tunneling method to encapsulate data
in the pseudowire.
Step 9
interworking ethernet
Example:
Router(config-pw)# interworking ethernet
Enables the L2VPN Interworking feature, and causes
Ethernet frames to be extracted from the attachment
circuit and sent over the pseudowire. Ethernet end-to-end
transmission is assumed. Attachment circuit frames that
do not contain Ethernet frames are dropped. In the case
of VLAN, the VLAN tag is removed, which leaves a pure
Ethernet frame.
Step 10
exit
Exits the xconnect configuration mode.
Step 11
interface port-channel number
Example:
Router(config)# interface port-channel 1
Creates an EtherChannel interface on the Cisco Cable
Modem Termination System (CMTS).
