Configuring MPLS Layer 2 VPNs
Configuring Gigabit EtherChannel for Virtual Private Wire Service
22
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
DETAILED STEPS
Command or Action Purpose
Step 1
enable
Changes the privilege level for the corresponding CLI
session.
Step 2
configure terminal
Example:
Router# configure terminal
Enters the global configuration mode.
Step 3
mpls label protocol ldp
Example:
Router# mpls label protocol ldp
Specifies that LDP is the default label distribution
protocol.
Step 4
interface loopback loopback-interface-number
Example:
Router# interface loopback 1
Specifies the loopback interface, and enters the interface
configuration mode.
Step 5
ip address ip-address mask
Example:
Router# ip address 10.10.2.1 255.255.255.0
Sets the IP address and mask for the loopback interface.
Step 6
exit
Exits the interface configuration mode.
Step 7
pseudowire-class pw-class-name
Example:
Router(config)# pseudowire-class gec-bridged
Specifies the name of a Layer 2 pseudowire class and
enters the pseudowire class configuration mode.
Step 8
encapsulation mpls
Example:
Router(config-pw)# encapsulation mpls
Uses MPLS as the tunneling method to encapsulate data
in the pseudowire.
Step 9
interworking ip
Example:
Router(config-pw)# interworking ip
Enables the L2VPN Interworking feature, and causes IP
packets to be extracted from the attachment circuit and
sent over the pseudowire. Attachment circuit frames that
do not contain IPv4 packets are dropped.
Step 10
exit
Exits the xconnect configuration mode.
Step 11
interface port-channel number
Example:
Router(config)# interface port-channel 1
Creates an EtherChannel interface on the Cisco Cable
Modem Termination System (CMTS).
Step 12
xconnect peer-ip-address vc-id encapsulation mpls
pseudowire-class pw-class-name
Example:
Router(config-if)# xconnect 10.0.0.1 707
encapsulation mpl pseudowire-class gec-routed
Binds an attachment circuit to a pseudowire to configure
an AToM static pseudowire, specifies MPLS as the
tunneling method, and enters the xconnect configuration
mode.
