Configuring and Accessing the Web User Interface
Configuring the Router for Web User Interface Access
6
Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
Step 4 Create and name a persistent web user interface transport map by entering the transport-map type
persistent webui transport-map-name command.
Step 5 Enable HTTP, HTTPS, or both by entering the following commands in transport map configuration
mode:
• server—Enables HTTP.
• secure-server—Enables HTTPS.
Port numbers cannot be set within the transport map. The port numbers defined in St
ep 3 are also used
with these settings in the persistent w
eb user interface transport map.
Step 6 (Optional) Enter the show transport-map name transport-map-name privileged EXEC command to
verify that your transport map is properly configured.
Step 7 Enable the transport map by entering the transport type persistent webui input transport-map-name
global configuration command.
Examples
In the following example, the web user interface using the default HTTP port is enabled:
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# ip http server
Router(config)# transport-map typ
e persistent webui http-webui
Router(config-tmap)# server
Router(config-tmap)# exit
Router(config)# exit
Router# s
how transport-map name http-webui
Transport Map:
Name: http-webui
Type: Persistent Webui Transport
Webui:
Server: enabled
Secure Server: disabled
Router# c
onfigure terminal
Router(config)# transport type pe
rsistent webui input http-webui
*Apr 22 02:43:55.798: %UICFGEXP-6-SERVER_NOTIFIED_START: R0/0: psd: Server wui has been
notified
to start
In the following example, the web user interface using the default HTTPs port is enabled:
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# ip http secure-se
rver
Router(config)# transport-map typ
e persistent webui https-webui
Router(config-tmap)# secure-serve
r
Router(config-tmap)# exit
Router(config)# transport type pe
rsistent webui input https-webui
*Apr 22 02:38:43.597: %UICFGEXP-6-SERVER_NOTIFIED_START: R0/0: psd: Server wui has been
notified to
start
In the following example, the web user interface using the default HTTP and HTTPS ports is enabled:
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# ip http server
Router(config)# ip http secure-se
rver

Cisco ASR1006 - ASR 1006 Modular Expansion Base Specifications

General

Rack Units	6U
Form Factor	Rack-mountable
Operating Temperature	32 to 104°F (0 to 40°C)
Product Type	Router
Slots	6
Redundancy	Redundant Power Supply Supported
Maximum Throughput	100 Gbps
Dimensions	17.5" Width
Weight	Approximately 130 lbs (59 kg)
Interfaces/Ports	Varies by installed modules
Memory	4 GB
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Relative Humidity	5% to 95% (noncondensing)
Compliance	CE, UL
