Cisco Catalyst IW9167I - Preinstallation Checks and Installation Guidelines

Figure 9: IW9167I - Dual Band Composite Radiation Pattern (5-GHz
Elevation)
Figure 8: IW9167I - Dual Band Composite Radiation Pattern (5-GHz
Azimuth)
Figure 11: IW9167I - Composite Radiation Pattern (6-GHz Elevation)Figure 10: IW9167I - Composite Radiation Pattern (6-GHz Azimuth)
Cisco Catalyst IW9167I Heavy Duty Access Point Hardware Installation Guide
9
About Cisco Catalyst IW9167I Heavy Duty Access Point
IW9167I (Internal Antenna) Radiation Patterns
