Figure 13: IW9167I - IoT (BLE) Antenna - Radiation Pattern (2.4-GHz
Elevation)
Figure 12: IW9167I - IoT (BLE) Antenna - Radiation Pattern (2.4-GHz
Azimuth)
Figure 15: IW9167I - Scanning Radio-Tri Band Composite Radiation
Pattern (2.4-GHz Elevation)
Figure 14: IW9167I - Scanning Radio-Tri Band Composite Radiation
Pattern (2.4-GHz Azimuth)
