Figure 40. SNMP dialog (SNMP disabled)
NOTE
By default, Fluidmesh units are shipped from the
factory with SNMP disabled.
Using SNMP v2c
To change the unit's SNMP mode to v2c and configure the unit
accordingly, do the following steps:
1. Click the SNMP mode drop-down, and click the v2c option.
• The SNMP v2c settings dialog will be shown (Figure 41
(page 104)).
Figure 41. SNMP dialog (v2c selected)
2. Enter a community identity value in the Community ID: field.
IMPORTANT
The same community identity value must be set for
all Fluidmesh units in the wireless network.
Cisco Ultra-Reliable Wireless
Backhaul FM4200 Mobi
© 2020 Cisco and/or its affiliates. All rights reserved. Page 104 of 177
