• The L2TP configuration settings window will be shown.
3. When the L2TP configuration has been set, save the settings by
clicking the Save button. Alternatively, clear the settings by
clicking the Reset button.
IMPORTANT
A detailed description of L2TP configuration methods is
beyond the scope of this manual. For detailed instructions on
how to set the L2TP configuration, refer to the Fluidmesh
Networks L2TPv3 Configuration Manual.
7.6.11. VLAN settings
VLAN configuration
The VLAN SETTINGS window contains controls to connect the Cisco
FM4200 Mobi to one or more virtual local area networks (VLANs) that are
part of the local wireless network.
IMPORTANT
The VLAN feature must be enabled using a software plug-in
(Fluidmesh part number FM-VLAN). Contact your Fluidmesh
Networks representative for details.
The Cisco FM4200 Mobi features smart self-management of integration
with connected VLANs, with minimal configuration time and avoidance of
potential configuration errors. This is done by A) relying on the data-
processing configuration of a connected network switch, and B) obeying
predefined rules for management of incoming and outgoing data packets.
IMPORTANT
For detailed information on the predefined rules for smart
VLAN packet management, refer to the “Rules for packet
management” (page 118) table at the bottom of this section.
To connect the unit to a VLAN that is part of the local wireless network, do
the following steps:
1. Click the -vlan settings link under ADVANCED SETTINGS in the
left-hand settings menu.
• The VLAN SETTINGS dialog will be shown (Figure 46
(page 118)).
Cisco Ultra-Reliable Wireless
Backhaul FM4200 Mobi
© 2020 Cisco and/or its affiliates. All rights reserved. Page 117 of 177
