3. SNMP traps can be enabled for significant system-related events.
If needed, enable SNMP event traps by checking the Enable
SNMP event trap: check-box, and enter the name of the network
management station (NMS) host in the NMS hostname: field.
IMPORTANT
The NMS host to which traps are sent must have an
SNMP agent that is configured to collect SNMP v2c
traps.
4. You can also configure the unit to send SNMP traps at defined
periodic intervals. If needed, enable periodic SNMP traps by
checking the Enable SNMP periodic trap: check-box, and enter
the name of the network management station (NMS) host in the
NMS hostname: field.
5. Save the SNMP settings by clicking the Save button.
Alternatively, clear the settings by clicking the Reset button.
Using SNMP v3
To change the unit's SNMP mode to v3 and configure the unit accordingly,
do the following steps:
1. Click the SNMP mode drop-down, and click the v3 option.
The SNMP v3 settings dialog will be shown (Figure 42
(page 106)).
Cisco Ultra-Reliable Wireless
Backhaul FM4200 Mobi
© 2020 Cisco and/or its affiliates. All rights reserved. Page 105 of 177
