Figure 48. Configurator GUI (MISC SETTINGS dialog)
2. Set the device name by typing it in the Name: field.
NOTE
It is not essential to specify the device name, but it is
strongly recommended. Failure to specify the device
name may make the unit difficult to recognize in
situations where more than one unit is being dealt
with at the same time (for example, when using
utilities such as the FMQuadro network map).
3. Set the functionality of the unit's hardware Reset button by
clicking the Reset Button function: drop-down and clicking the
needed option as described below:
Disabled: The hardware Reset button will be disabled.
NOTE
If the Disabled option is chosen, you can still
reboot or do a hard reset of the unit using the
Configurator GUI. See “Resetting the unit to
factory defaults” (page 141) for more
information.
Enabled: The hardware Reset button will be enabled.
Factory: The hardware Reset button functionality will be
set to its factory default configuration (enabled).
Cisco Ultra-Reliable Wireless
Backhaul FM4200 Mobi
© 2020 Cisco and/or its affiliates. All rights reserved. Page 125 of 177
