Cisco IE 4000 Hardware Installation Guide

60
Technical Specifications
Technical Specifications
Technical Specifications
The technical specifications for the Cisco IE 4000 switches are as follows:
Table 4 Cisco IE 4000 Technical Specifications
Environmental Ranges
Storage temperature –40 to 185°F (–40 to 85°C)
Operating temperature
1
-40C to +74C
 -40C to +70C (Vented Enclosure Operating)
 -40C to +60C (Sealed Enclosure Operating)
 -34C to +74C (100LFM or more Fan or Blower equipped Enclosure
Operating)
-40C to +85C (Type Tested to +85C for 16 hours)
2
Note: If the unit is powered on at subzero temperatures it could take up to 12
minutes to complete the booting process. This is due to the internal heaters
that heat up the devices to safe operating temperature.
Operating humidity 5 to 95% (noncondensing)
Operating shock 30 g at 11 ms, and 200 g at 2.11 ms.
Operating altitude Up to 13,000 ft (3962 m)
Storage altitude Up to 40,000 ft (12,192 m)
Power Requirements
DC input voltage  Maximum operating range: 9.6 to 60 VDC
 Nominal: 12, 24, or 48 VDC
Note:
 The DC-input power supply is an SELV circuit, and it can only be
connected to another SELV circuit.
 Input voltage for power supplies:
— To power the switch, PWR-IE50W-AC-IEC and PWR-IE50W-AC
provide 24 VDC at 2.1 A.
— To support PoE, power supplies PWR-IE65W-PC-AC and
PWR-IE65W-PC-DC provide 54 VDC at 1.2 A.
 PoE mode vs PoE+ input voltages
— PoE mode: 48 VDC (nominal)/44-57 VDC (absolute range)
— PoE+ mode: 54 VDC (nominal)/50-57 VDC (absolute range)

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
