Cisco IE 4000 Hardware Installation Guide

66
Cable and Connectors
Cables and Adapters
 A mode-field diameter/cladding diameter = 9 micrometers/125 micrometers.
 A mode-conditioning patch cord is required when using 1000BASE-LX/LH SFP modules, MMF, and a short link
distance . Using an ordinary patch cord can cause transceiver saturation, resulting in an elevated bit error rate (BER).
When using the LX/LH SFP module with 62.5-micron diameter MMF, you must also install a mode-conditioning patch
cord between the SFP module and the MMF cable on both the sending and receiving ends of the link. The
mode-conditioning patch cord is required for link distances greater than 984 feet (300 m).
 1000BASE-ZX SFP modules can send data up to 62 miles (100 km) by using dispersion-shifted SMF or
low-attenuation SMF. The distance depends on the fiber quality, the number of splices, and the connectors.
 When the fiber-optic cable span is less than 15.43 miles (25 km), insert a 5-decibel (dB) or 10-dB inline optical
attenuator between the fiber-optic cable plant and the receiving port on the 1000BASE-ZX SFP module.
Table 6 Commercial SFPs—Fiber-Optic SFP Module Port Cabling Specifications
Type of SFP Module Model Wavelength
(nanometers)
Fiber
Type
Core
Size/Claddin
g Size
(micron)
Modal
Bandwidth
(MHz/km)
Cable Distance
1000BASE-BX10-D GLC-BX-D 1490 TX
1310 RX
SMF G.652 — 6.2 miles (10 km)
1000BASE-BX10-U GLC-BX-U 1490 TX
1310 RX
SMF G.652 — 6.2 miles (10 km)
1000BASE-LX/LH GLC-LH-SM 1310 MMF
SMF
62.5/125
50/125
50/125
G.652
500
400
500
—
1804 feet (550 m)
1804 feet (550 m)
1804 feet (550 m)
6.2 miles (10 km)
1000BASE-SX GLC-SX-MM 850 MMF 62.5/125
62.5/125
50/125
50/125
160
200
400
500
722 feet (220 m)
902 feet (275 m)
1640 feet (500 m)
1804 feet (550 m)
1000BASE-SX GLC-SX-MMD 850 MMF 62.5/125
62.5/125
50/125
50/125
160
200
400
500
722 feet (220 m)
902 feet (275 m)
1640 feet (500 m)
1804 feet (550 m)
100BASE-BX10-D GLC-FE-100BX
-D
1310 TX
1550 RX
SMF G.652 — 6.2 miles (10 km)
100BASE-EX GLC-FE-100EX 1310 SMF G.652 — 24.9 miles (40 km)
100BASE-FX SFP GLC-FE-100FX 1310 MMF 50/125
62.5/125
500 6562 feet (2 km)
100BASE-LX10 GLC-FE-100LX 1310 SMF G.652 — 6.2 miles (10 km)

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
