Catalyst 4500 E-Series Switches Installation Guide
OL-13972-02
Chapter 1 Product Overview
Catalyst 4506-E Switch
Ta b l e 1-3 Catalyst 4506-E Switch Features
Feature Description
Chassis Six horizontal slots. Slots are numbered from 1 (top) to 6 (bottom).
Supervisor engines • Supports the following supervisor engines:
– Supervisor Engine 7-E
– Supervisor Engine 6L-E
– Supervisor Engine 6-E
– Supervisor Engine V-10GE
– Supervisor Engine V
– Supervisor Engine IV
– Supervisor Engine II-Plus-10GE
– Supervisor Engine II-Plus
Note Refer to your software release notes for the minimum software
release versions required to support the supervisor engines.
• Supervisor engines must be installed in slot 1.
• Supervisor engine redundancy is not supported in this chassis.
Modules • Supports up to five Catalyst 4500 series modules.
• Some Catalyst 4500 series modules may:
– Not be supported
– Require that you install a specific supervisor engine
– Have chassis slot restrictions
– Require a specific software release level to operate
• Check your software release notes for specific information.
Backplane 48 Gbps full duplex per slot (240 Gbps)
Port density • 10/100 (RJ-45)—240 ports
• 10/100 with PoE (RJ-45)—240 ports
• 10/100 with or without PoE (RJ-21)—240 ports
• 100FX (MT-RJ)—240 ports
• 100LX-10 (MT-RJ) or 100BX-D (LC)—240 ports
• 1000BASE-X—244 ports
• 10/100/1000BASE-T—240 ports
• 10/100/1000BASE-T with PoE—240 ports
• 10GBASE-X—32 ports
Inline power Integrated support, 820 W per switching module
