StateStatusColorFunctionLocationIndicator
No input to the PSU.OffGreenPSU input/outputFaceplate of
each PSU
PSU Status
Indicators
PSU output is OK.Solid on
PSU output is not OK, but
input is OK.
Blinking
PSU is operating normally.OffAmberPSU operation
Any of the following
conditions exists in the
PSU:
Over voltage
Over current
Over temperature
Fan failure.
Solid on
PSU has a fault, but is still
operating.
Blinking
Fan module is operating
normally.
Solid onGreenFan module heathFaceplate of
each Fan
Module
Fan Status
All fans in the fan module
have failed.
Solid onAmber
The following table describes the Ethernet ports LEDs for the Cisco MDS 9132T switch.
StateStatusLED Position
There is no link.OffLeft
Indicates a physical link.Green
There is no activity.OffRight
Indicates activity.Blinking Green
The following table describes the Fibre Channel ports LEDs for the Cisco MDS 9132T switch.
StateStatus
The link is up.Solid Green
The link is up and the port beacon is active.Regular flashing Green
Cisco MDS 9132T Fibre Channel Switch Hardware Installation Guide
15
Product Overview
Switch LEDs
