Chassis handles
Handles are to be used only for positioning an empty
chassis.
Note
6
Grid A PSU bays (1, 2, 5, 6)7
Grid B PSU bays (3, 4, 7, 8)8
The following figure shows the rear view of the Cisco MDS 9710 chassis.
Figure 4: Cisco MDS 9710 Chassis Rear View
Cisco MDS 9700 Series Switches Hardware Installation Guide
17
Product Overview
Cisco MDS 9710 Director Chassis

Cisco MDS 9700 Series Specifications
