The following table describes the LEDs on the Cisco MDS 9700 Series Supervisor-4 Module.
Table 3: Cisco MDS 9700 Series Supervisor-4 Module LEDs
DescriptionStatusLED
A user has activated this LED to allow a person to find this module in the chassis.Blinking blueID
Location identification is deactivated for this module.Off
All module diagnostics passed. The module is operational.
GreenStatus
Indicates one of the following conditions:
• The module has detected an error and cannot power on or boot up.
• The module is not properly inserted.
• A bootup or runtime diagnostic test has failed.
Red
Indicates one of the following conditions:
• An over temperature condition has occurred. (A major temperature threshold has
exceeded during an environmental monitoring.)
• The module is resetting.
• The ejector lever is open.
Blinking Red
The module is not receiving power.Off
All environmental sensors in the system are within operational bounds.
GreenSystem
At least one power supply has failed or the power supply fan has failed.Amber
The temperature of the supervisor module exceeded the major threshold.Red
The supervisor is operational and in the HA-active state.
GreenActive
The supervisor module is in the HA-standby state.Amber
There is sufficient power available for all installed modules.
GreenPower Management
There is insufficient power for all installed modules.Amber
The mgmt0 interface is administratively active when the supervisor is in the HA-active
state.
GreenMGMT0 Ethernet
From Cisco MDS NX-OS Release 8.4(2), when the supervisor is in HA-standby state,
the mgmt0 interface is not administratively active.
On Cisco MDS NX-OS Release 8.4(1a) or earlier, when the supervisor is in the
HA-standby state, the mgmt0 interface is not administratively active.
Amber
The mgmt0 interface is uninitialized. No signal is detected.Off
Frames are being transmitted or received by the interface.
GreenACT
There is no activity on the interface.Off
Cisco MDS 9700 Series Switches Hardware Installation Guide
24
Product Overview
Cisco MDS 9700 Series Supervisor-4 Module
