Cisco MDS 9700 Series User Manual

MGMT Ethernet: MGMT0 Ethernet out of band port4
ACT: management port packet activity LED5
Console Serial Port: module serial console port6
Eject Request: eject request button for USB1 device7
USB1: usb1 status LED8
USB1: USB port (USB 3.0)9
Slot0: slot0 status LED10
Eject Request: eject request button for a slot0 device11
Reset: module reset button12
Module lock release button13
Status: system diagnostic test status LED14
System: system environment status LED15
Active: supervisor redundancy status LED16
PWR MGMT: system power status LED17
Management port operational status LED18
Module ejection lever19
Slot0: USB port (USB 2.0)20
The following table describes the LEDs on the Cisco MDS 9700 Series Supervisor-1 Module.
Table 5: Cisco MDS 9700 Series Supervisor-1 Module LEDs
DescriptionStatusLED
A user has activated this LED to allow a person to find this module in the chassis.Blinking blueID
Location identification is deactivated for this module.Off
