Figure 58: Positioning the Top Hood with the Upper Cable Management Assemblies and the Switch Chassis
Alignment
holes
2Alignment
pins
1
Step 6 Use four M4x8 pan-head screws to loosely fasten the top hood to the chassis as shown in Figure 59: Fastening the Top
Hood to the Chassis and Cable Management Assemblies, on page 114.
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
113
Installing a Cisco Nexus 7018 Chassis
Installing the Cable Management Frame
