Transmit and Receive
Wavelength (nm)
Receive Power (dBm)Transmit Power (dBm)Transceiver TypeX2 Transceiver
Product Number
1260 to 13550.5 (maximum)
–8.4 (minimum) (in average)
–6.4 (minimum) (in OMA)
22
0.5 (maximum)
–6.5 (minimum)
10GBASE-LRM, 1310-nm
MMF and SMF
SFP-10G-LRM
840 to 860–1.0 (maximum)
–9.9 (minimum)
–1.2 (maximum)
23
–7.3 (minimum)
10GBASE-SR, 850-nm
MMF
SFP-10G-SR
22
Both the average and the OMA specifications must be met simultaneously.
23
The launch power shall be the lesser of the class 1 safety limit or the maximum receive power. Class 1 laser requirements are
defined by IEC 60825-1:2001.
Table 48: Environmental and Power Specifications for the 10-Gigabit SFP+ Transceivers and FETs
SpecificationParameter
–40 to 185°F (–40 to 85°C)Storage temperature
32 to 158°F (0 to 70°C)Operating temperature
32 to 158°F (0 to 70°C)Case temperature
3.1 to 3.5 VModule supply voltage
10BASE-DWDM SFP+ Transceivers
The Dense Wavelength Division Multiplexing (DWDM) SFP+ transceivers are part of a DWDM optical
network to provide high-capacity bandwidth across a fiber-optic network. There are 32 fixed-wavelength
DWDM SFP+ transceivers that support the International Telecommunications Union (ITU) 100-GHz
wavelength grid. These transceivers have duplex SC connectors. DWDM SFP+ transceivers can transmit and
receive optical signals up to 50 miles (80 km) depending on the quality of the fiber-optic cable used.
DWDM SFP+ transceivers look like the typical 10GBASE-X SFP+ transceivers as shown in Figure 147:
SFP+ Transceivers and FETs, on page 216.
For the specifications that differentiate the 10GBASE-DWDM SFP+ transceivers, see the 10-Gigabit Ethernet
Transceiver Modules Compatibility Matrix .
10-Gigabit X2 Transceivers
Starting with Cisco NX-OS Release 8.0(1), the 8-port 10-GB Ethernet (N7K-M108X2-12L) I/O modules are
not supported.
Note
The following 10-Gigabit X2 transceivers are used with the 8-port 10-GB Ethernet (N7K-M108X2-12L) I/O
modules:
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
218
Transceivers and Module Connectors
10BASE-DWDM SFP+ Transceivers
