Cisco Nexus 9508 - Power Supply LEDs

StatusColorLED
The operator has activated this LED to identify this module in the
chassis.
Flashing blueBCN
This LED is not being used.Off
All diagnostics passed. This module is operational (normal
initialization sequence).
GreenSTS
Indicates one of the following:
•
The module has detected a slot ID parity error and will not
power on or boot up.
•
The module is not fully inserted, and it is not making a reliable
connection with the supervisor.
•
The module has failed diagnostic tests and has powered down.
•
An overtemperature condition has occurred. A major
temperature threshold has been exceeded during environmental
monitoring.
Flashing red
Indicates one of the following:
•
The module is booting up or initializing.
•
The module is resetting and both ejector levers are out.
•
The module has been inserted during the initialization process.
•
The module could not power up because of insufficient power.
Flashing amber
The module is not receiving power.Off
The port is active (the link is connected and active).GreenLink (for
each port)
The port is disabled by the operator or is not initializing.Orange
The port is faulty and disabled.Flashing orange
The port is not active or the link is not connected.Off
Power Supply LEDs
The power supply LEDs are located on the upper left front portion of the module. Combinations of states
indicated by the OK and FAIL (or FAIL/ID) LEDs indicate the status for the module as shown in the following
table.
