48-port 1/10-GBASE-T and 4-port 10/40-Gigabit Ethernet QSFP+ line card (N9K-X9564TX)
•
Line cards supported by N9K-C9508-FM-E fabric modules
◦
32-port 40/100-Gigabit Ethernet QSFP28 line card (N9K-X9732C-EX) supporting 1 x 100, 2 x
50, 1 x 40, 4 x 10, 1 x 10, and 1 x 1 Gigabit Ethernet
◦
48-port 10/25-Gigabit Ethernet SFP28 and 4-port 40/100-Gigabit Ethernet QSFP28 line card
(N9K-X97160YC-EX)
•
Line cards supported by N9K-C9508-FM-R fabric modules
◦
36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-RX) with TCAM
◦
36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-R)
◦
36-port 40-Gigabit Ethernet QSFP+ line card (N9K-X9636Q-R)
•
Line cards supported by N9K-C9508-FM-S fabric modules
◦
32-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9432C-S) supporting 1 x 100, 2 x 50, 1 x
40, 4 x 10, and 1 x 1 Gigabit Ethernet
Accessing an Line Card Through a Console
You can troubleshoot bootup problems for an line card by accessing the module through its console port. This
action establishes a console mode that you must exit in order to use other Cisco NX-OS commands.
To attach to the console port for an line card, use the attach console module command to specify the module
that you need to work with.
Use the attach console module slot_number command to attach the console to a specific line card.
switch# attach console module 3
connected
Escape character is `~,' (tilde comma]
To exit the console mode, enter the ~, command.Note
Overview of Fabric Modules
The following table lists the types and quantities of fabric modules required by the line cards installed in the
switch. The switch can have only one type of fabric module installed and only the line cards supported by
that type of fabric module.
If you downgrade the release of the NX-OS software, be sure that the switch is using fabric modules
supported by the new release. The following table lists the first software release that supports each type
of fabric module.
Note
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
66
Managing the Switch
Accessing an Line Card Through a Console
