Cisco Nexus 9508 - Weights and Quantities for the Chassis, Modules, Fan Trays, and Power Supplies

HeightDepthWidthChassis or Module
1.75 inches (4.4 cm)Inside chassis: 20.67
inches (52.5 cm)
Ejector levers outside
chassis: 0.75 inches (1.9
cm)
Without mounting
brackets: 7.0 inches
(17.78 cm)
With mounting brackets:
8.0 inches (20.32 cm)
Supervisor modules
1.42 inches (3.61 cm)Inside chassis: 10.74
inches (27.28 cm)
Ejector levers outside
chassis: 0.75 inches (1.9
cm)
Without mounting
brackets: 6.81 inches
(17.3 cm)
With mounting brackets:
7.81 inches (19.84 cm)
System controller
modules
1.75 inches (4.4 cm)Inside chassis: 16.5
inches (41.91 cm)
Ejector levers outside
chassis: 2.5 inches (6.35
cm)
17.0 inches (43.18 cm)Line cards
16.4 inches (41.66 cm)11.7 inches (29.72 cm)2.46 inches (6.25 cm)Fabric modules
Without mounting
brackets: 16.5 inches
(41.91 cm)
With mounting brackets:
18.08 inches (45.92 cm)
5.12 inches (13.0 cm)5.04 inches (12.81 cm)Fan trays
1.75 inches (4.4 cm)Inside chassis: 17.75
inches (44.96 cm)
Ejector levers outside
chassis: 0.75 inches (1.9
cm)
5.25 inches (13.33 cm)Power supply
Weights and Quantities for the Chassis, Modules, Fan Trays,
and Power Supplies
QuantityWeight per UnitComponent
1150.0 lb (68.2
kg)
Cisco Nexus 9508 Chassis (N9K-C9508)
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
114
System Specifications
Weights and Quantities for the Chassis, Modules, Fan Trays, and Power Supplies
