When the lever is fully rotated away from the
module, the knob at the other end of the lever
can no longer hold the module in the slot.
3Fully press and hold the release button on each ejector
lever.
1
Fully rotate both ejector levers away from the module.2
To prevent damage to the ejector lever, you must press and hold the release button on each ejector lever
before rotating the lever 45 degrees from the module.
Caution
c) Pull both levers to partially slide the line card out of its slot in the chassis as shown in the following figure.
Pull both levers to partially remove the line card from
the chassis.
1
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
85
Replacing or Installing Modules, Fan Trays, and Power Supplies
Installing or Replacing a Line Card
