Status and Statistics
Viewing TCAM Utilization
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 24
2
STEP 5 Click View All Interfaces Statistics to see the statistics counters for all interfaces
on a single page. The Etherlike Statistics Table displays the statistics counters for
all interfaces. From this page you can perform the following actions:
• Select the refresh rate from the Refresh Rate drop-down menu.
• Select an interface and click Clear Interface Counters to clear the statistics
counters for the selected interface.
• Click Clear All Interface Counters to clear the statistics counters for all
interfaces.
• Select an interface and click View Interface Statistics to see the statistics
counters for the selected interface on a single page.
• Click Refresh to manually refresh the statistics counters for all interfaces.
Viewing TCAM Utilization
The switch architecture uses a Ternary Content Addressable Memory (TCAM) to
support packet actions in wire speed. TCAM holds the rules produced by
applications (such as ACL and QoS) and the system-created rules.
Only system application allocates rules upon its initiation.
To view TCAM utilization, click Status and Statistics > TCAM Utilization.
The following fields are displayed:
• Maximum TCAM Entries—Maximum TCAM entries available.
• In Use—Number of TCAM entries that are currently using.

Cisco SG220-26P Specifications

General

Model	SG220-26P
Ports	26
PoE Ports	24
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
Power Supply	Internal
VLANs Supported	256
Management	Web-based GUI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 x 44 x 257 mm
Weight	3.3 kg
