Cisco SG220-26P Administration Guide

Administration: System Logs
Viewing Memory Logs
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 41
3
Viewing Flash Memory Logs
The Flash Memory page displays the messages that are stored in flash memory in
chronological order. The minimum severity for logging is configured on the Log
Settings page. Flash logs remain when the switch is rebooted. You can clear the
logs manually.
To view flash logs:
STEP 1 Click Status and Statistics > View Log > Flash Memory.
The following fields are displayed:
• Log Index—Log entry number.
• Log Time—Time when message was generated.
• Severity—Event severity.
• Description—Message text describing the event.
STEP 2 Click Clear Logs to clear the log messages.

Cisco SG220-26P Specifications

General

Model	SG220-26P
Ports	26
PoE Ports	24
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
Power Supply	Internal
VLANs Supported	256
Management	Web-based GUI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 x 44 x 257 mm
Weight	3.3 kg
