Getting Started
Quick Start Switch Configuration
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 15
1
The initial page displayed depends on the “Do not show this page on startup”
option on the Getting Started page. If you did not select this option, the initial page
is the Getting Started page. If you did select this option, the initial page is the
System Summary page.
Quick Start Switch Configuration
To simplify switch configuration through quick navigation, the Getting Started
page provides links to the most commonly used pages.
Category Link Name (on the Page) Linked Page
Initial
Setup
Change Management
Applications and Services
Security > TCP/UDP Services
page
Change Device IP Address Administration > Management
Interface > IPv4 Interface page
Create VLAN VLAN Management > Create
VLAN page
Configure Port Settings Port Management > Port Setting
page
Device
Status
System Summary Status and Statistics > System
Summary page
Port Statistics Status and Statistics > Interface
page
RMON Statistics Status and Statistics > RMON >
Statistics page
View Log Status and Statistics > View Log >
RAM Memory page

Cisco SG220-26P Specifications

General

Model	SG220-26P
Ports	26
PoE Ports	24
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
Power Supply	Internal
VLANs Supported	256
Management	Web-based GUI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 x 44 x 257 mm
Weight	3.3 kg
