Quality of Service
Workflow to Configure QoS Settings
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 256
18
STEP 3 Click Apply. DSCP values to queues are mapped, and the Running Configuration is
updated.
STEP 4 Click Restore Defaults to restore the DSCP to Queue mappings to factory
defaults.
Mapping Queues to CoS/802.1p
Use the Queues to CoS/802.1p page to remark the CoS/802.1p priority for egress
traffic from each queue.
To map queues to CoS values:
STEP 1 Click Quality of Service > General > Queues to CoS/802.1p.
STEP 2 For each output queue, select the CoS/802.1p priority to which egress traffic from
the queue is remarked.
STEP 3 Click Apply. The Running Configuration is updated.
STEP 4 Click Restore Defaults to restore the Queue to CoS/802.1p mappings to factory
defaults.
Mapping Queue to IP Precedence
To map egress queue to IP precedence:
STEP 1 Click Quality of Service > General > Queues to IP Precedence.
STEP 2 For each output queue, select the IP precedence to which egress traffic from the
queue is remarked.
STEP 3 Click Apply. The Running Configuration is updated.
STEP 4 Click Restore Defaults to restore the queue to IP precedence mappings to factory
defaults.
