Cisco SG220-26P Administration Guide

Quality of Service
Workflow to Configure QoS Settings
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 260
18
To define the VLAN ingress rate limit:
STEP 1 Click Quality of Service > General > VLAN Ingress Rate Limits.
STEP 2 Click Add.
STEP 3 Enter the following information:
• VLAN ID—Select a VLAN.
• Committed Information Rate (CIR)—Enter the average maximum amount
of data that can be accepted into the VLAN in kilobytes per second.
STEP 4 Click Apply. The Running Configuration is updated.
Configuring VLAN Port Rate Limit
Rate limiting per VLAN port, performed on the VLAN Port Ingress Rate Limit page,
enables traffic limiting on the ports that are bound to a specific VLAN.
When VLAN port ingress rate limiting is configured, it limits aggregate traffic from
the specified ports on the switch.
This feature requires that the switch is in QoS basic mode or in QoS advanced
mode.
If both bandwidth limitation and VLAN port ingress rate limit are enabled at the
same time, the smaller setting will take precedence.
To define the VLAN port ingress rate limit:
STEP 1 Click Quality of Service > General > VLAN Port Ingress Rate Limits.
STEP 2 Click Add.
STEP 3 Enter the following information:
• VLAN ID—Select a VLAN.
• Committed Information Rate (CIR)—Enter the average maximum amount
of data that can be accepted into the specified interfaces in kilobytes per
second.
• Interface—Enter an interface or a range of interfaces. The interfaces must
be bound to the selected VLAN.

Cisco SG220-26P Specifications

General

Model	SG220-26P
Ports	26
PoE Ports	24
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
Power Supply	Internal
VLANs Supported	256
Management	Web-based GUI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 x 44 x 257 mm
Weight	3.3 kg
