Page #179 background image
Multicast Forwarding
Configuring Multicast Filtering
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 177
14
Configuring Interface Filter Settings
Configuring Multicast Filter Profiles
A Multicast filter profile permits or denies a range of Multicast groups to be
learned when the join group matches the filter profile IP group range.
To create a Multicast filter profile:
STEP 1 Click Multicast > Multicast Filtering > Profiles.
STEP 2 Select either Version 4 or Version 6 that the filter profile is applied to IPv4 or IPv6
Multicast traffic, and click Go.
STEP 3 Click Add.
STEP 4 Enter the following information:
Profile Index—Enter the sequence number for the profile.
IP Version—Select ether Version 4 or Version 6 to apply the filter profile to
IPv4 or IPv6 Multicast traffic.
Start Multicast Address—Enter the starting Multicast group address.
End Multicast Address—Enter the ending Multicast group address.
Action—Denies or permits Multicast frames when the join group matches
the profile IP group range.
STEP 5 Click Apply. The Running Configuration is updated.
Configuring Interface Filter Settings
To assign a Multicast filter profile to an interface to deny or permit the Multicast
group when the join group matches the filter profile:
STEP 1 Click Multicast > Multicast Filtering > Filter Settings.
STEP 2 Select the IP version and the interface type (Port and LAG), and click Go.
STEP 3 Select an interface and click Edit.
STEP 4 Enter the following information:
