Multicast Forwarding
Configuring Multicast Filtering
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 178
14
• Interface—Select the port or LAG to be defined.
• Filter—Enable or disable filtering Multicast traffic on this interface.
• Filter Profile Index—If enabled, select the Multicast filter profile to be
applied. The Multicast filter settings defined in the profile are applied to the
interface.
STEP 5 Click Apply. The Running Configuration is updated.

Cisco SG220-26P Specifications

General

Model	SG220-26P
Ports	26
PoE Ports	24
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
Power Supply	Internal
VLANs Supported	256
Management	Web-based GUI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 x 44 x 257 mm
Weight	3.3 kg
