Multicast Forwarding
Configuring Multicast Router Ports
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 174
14
STEP 3 Click Go. The following fields are displayed for each Multicast group:
• VLAN ID—The VLAN ID.
• IP Multicast Group Address—The Multicast group IP address.
• Member Ports—The list of ports to where the corresponding Multicast
stream is forwarded.
• Type—The group type is static or dynamic.
• Life (sec)—The dynamic group life time.
Configuring Multicast Router Ports
A Multicast router (Mrouter) port is a port that connects to a Multicast router. The
switch includes the Mrouter port(s) when it forwards Multicast streams and IGMP/
MLD registration messages. It is required in order for all Mrouters can, in turn,
forward the Multicast streams and propagate the registration messages to other
subnets.
Use the Multicast Router Port page to statically configure or see dynamically
detected ports connected to Mrouters.
To define Multicast router ports:
STEP 1 Click Multicast > Multicast Router Port.
STEP 2 Enter the query criteria:
• VLAN ID equals to—Select the VLAN ID for the router ports that are
described.
• IP Version equals to—Select either Version 4 or Version 6 that the
Multicast router supports.
• Interface Type equals to—Select the interface type (Port or LAG).
STEP 3 Click Go. The interfaces matching the query criteria are displayed.
STEP 4 For each interface, select its association type. The options are:
• Static—The port is statically configured as a Multicast router port.

Cisco SG220-26P Specifications

General

Model	SG220-26P
Ports	26
PoE Ports	24
Switching Capacity	52 Gbps
Forwarding Rate	38.69 Mpps
Layer	Layer 2
Power Supply	Internal
VLANs Supported	256
Management	Web-based GUI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Dimensions	440 x 44 x 257 mm
Weight	3.3 kg
