Cisco UCS C460 Installation And Service Guide

1-4
Cisco UCS C460 Server Installation and Service Guide
OL-22326-01
Chapter 1 Overview
Network and
management I/O
The server provides these rear-panel connectors:
• Two dedicated 10/100 Ethernet management ports
• Two 1Gb Ethernet ports
These integrated Gigabit ports support the Wake on LAN (WoL) and TCP/IP
Offload Engine (TOE) standards.
• Two 10Gb Base-T Ethernet ports
• Two 10Gb SFP+ Ethernet ports
Note See Using the 10 Gb Ports, page 2-12 for more information about the SFP+
and 10GBase-T 10 Gb ports.
• One DB9 serial connector.
• One 15-pin VGA
7
connector.
• Two USB
8
2.0 connectors.
The server provides these front-panel connectors:
• One 15-pin VGA connector.
• Three USB 2.0 connectors.
WoL The 1-Gb Base-T Ethernet LAN ports support the wake-on-LAN (WoL) standard.
Power Either 2 or 4 power supplies, 850W each. 
Hot-swappable, rear-accessible, and redundant as 2+2 or 3+1.
Note You can use 2 power supplies with a 2-CPU configuration. In this case, 1+1
redundancy is supported only if your server’s overall power consumption
can be supported by a single 850W power supply during the failure and
hot-swap. For more information about your server’s power consumption,
consult with your Cisco sales representative or use the power calculator
accessible at the Unified Computing System Partner Resource Center:
http://www.ciscoprc.com/resourcelib.asp?id=937
ACPI This server supports the advanced configuration and power interface (ACPI) 4.0
standard.
Cooling Up to 8 fans, hot-swappable, redundant as 7+1, or non-redundant as 4.
Also, there are 4 fans in each power supply for lower-section cooling.
Removable media One DVD drive.
The drive supports the following media types: CD-R, CD-ROM, CD-RW, DVD+R,
DVD+RW, DVD-R, DVD-ROM, DVD-RW, +R DL
1. DIMM = dual inline memory module
2. DDR = double data rate (transfer mode)
3. SAS = serial attached SCSI
4. SATA = serial advanced technology attachment
5. RAID = redundant array of independent disks
6. PCIe = peripheral component interconnect express
7. VGA = video graphics array
8. USB = universal serial bus
Table 1-1 Cisco UCS C460 Server Features (continued)
