Citizen CL-E321 User Manual

16
——
NAME Exterior appearance
Ribbon take-up core
USB cable
CD-ROM
Quick Start Guide
Safety Instructions
1.3 Model Classication
Model numbers indicate printer features according to the following system.
CL - E321 X E B N N X
1 2 3 4 5 6 7
1. Model name
CL-E321: 203 DPI
CL-E331: 300 DPI
2. Fixed value
3. Market
A: Asia
C: China
E: Europe
U: North America
4. Body case color
B: Black
W: Pure white
5. Interface
N: USB port, wired LAN, and serial port

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
