Citizen CL-E321 User Manual

78
——
5. Press the FEED key to select an emulation switching mode.
Each press of the FEED key cycles through the emulation mode options of DMX mode, ZPL
mode, and EPL mode.
Emulation mode Buzzer Status LED
Color Interval
DMX mode 1 short tones Green Flashes
Press the FEED key ↓
ZPL mode 2 short tones Green Flashes quickly
Press the FEED key ↓
EPL mode 3 short tones Amber Flashes
Press the FEED key↓
Returns to DMX mode.
6. Press and hold the FEED key for at least 3 seconds.
7. Release the FEED key once the buzzer emits a long tone and then press the FEED key
again.
The selected emulation mode is set, and the printer restarts.
 To cancel setting the emulation mode, continue pressing and holding the FEED key for
at least 3 seconds without releasing your nger at step 7.
The buzzer emits 4 short tones, and the printer restarts.
7.5 HEX Dump Mode
This mode is used to print a hex dump list (data received by the printer represented in
hex values) for conrmation of the data content.
Example of dump list printing
Load media and then perform the following procedure.
1. Turn on the power to the printer while pressing and holding the FEED key to start the
printer in special function mode.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
