Citizen CL-E321 User Manual

35
——
3.3 Loading a Ribbon
How to Load a Ribbon
1. Load the ribbon and ribbon take-up core onto the two ribbon shafts.
Ribbon shafts
Ribbon
Ribbon take-up core
CAUTION
 Fully insert the ribbon shafts all the way into the ribbon and ribbon take-up core.
 Use of ribbon with a width that is at least 5 mm wider than the width of the media to be used is
recommended.
 If using media with a width of 2 inches or less, we recommend using a 60-mm or wider ribbon.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
